Measurement Technique: Transit time and PT100 Class B 4 wireTurn Down Ratio: 200:01Heat Meter Standard: The Heat/Energy calculation is designed to comply with EN1434 section 6, third party certification pending.Accuracy: +/-1-3% of flow reading for >0.3m/sFlow Velocity Range: 0.1 to 10m/s
Pipe Range: 25mm – 115mm OD
Water Temp Range: 0°C to 85°C
Temperature sensors: Clamp-on PT100 Class B 4 wire, range 0 to 85°C, resolution 0.1 °C
Output:KWh energy or volume flow pulse
External Power Supply:12V-24V +/- 10% AC/DC at 7 watts
Electronics Enclosure:IP54
Input/Output Cable:5m x 6 core for power in and data out
Dimensions:250mm x 48mm x 90mm (electronics + guide rail)
Modbus Communication:Modbus RTU slave, RS485 serial link hardware layer.
