| Supply voltage via ALMEMO® device. Sensor cable connected via screw terminals, optional up to 30 m
|
FHA646WG ALMEMO® Wall-housing
sensor Type
● Supply voltage via
ALMEMO® device
● Sensor cable
connected via screw terminals,
optional up to 30 m
Accessories, Options:
| ZB9060K |
Sensor cable connected via screw terminals,
optional up to 30 m |
| Types: |
| FHA646WG |
Humidity / temperature sensor in wall-mount
housing incl.ALMEMO® connecting cable, 2 m |
|
| Technical Data: |
| Operative range : |
-20 to +60 °C, 0 to 90 % r.H.
(non-condensing) |
| Humidity measuring circuit |
| Measuring range: |
0 to 100% r.H. |
| Sensor: |
capacitive |
| Accuracy: |
± 2% r.H. at nominal temperature |
| Reproducibility: |
< 1% r.H. at nominal temperature |
| Nominal temperature: |
25°C ±3°C |
| Response time T90: |
approx. 10 s (without filter) at 5 m/s |
| Temperature measuring circuit |
| Sensor: |
NTC type N |
| Accuracy: |
| NTC: |
-20 … 0°C:
±0.4
0 … 60°C: ±0.1°C |
|
| Reproducibility: |
0.1°C |
| Mechanical construction |
| Sensor tube: |
PVC, 12 mm |
| Protective cap: |
SK7, metal-mesh filter |
| Housing: |
plastic, 123 x 68 x 49, IP40 |
|
| |
|
|
 | |
 |
|
 |
|
