| These Meters are excellent diagnostic instruments for detecting temperature and humidity. |
| TSI’s TH-CALC™ Meters are excellent diagnostic instruments for detecting temperature and humidity. Each hand held instrument measures multiple parameters. The Model 8720 measures temperature, humidity and calculates dewpoint. The Model 8722 adds data logging, and performs wet bulb temperature, absolute humidity and % outside air calculations. These instruments are ideal for conducting thermal comfort studies and Indoor Air Quality (IAQ) evaluations. |
| |
|
Features |
- Direct calculation of dewpoint temperature
- Sampling function records multiple point measurements
- Optional portable printer provides hard copy documentation of your measurements
- View two parameters simultaneously from the large digital display
|
| |
|
Additional Features and Benefits of the Model 8722 |
- Direct calculation of wet bulb temperature and absolute humidity - no psychrometric chart needed
- Automatically calculates % outside air after taking necessary temperature readings
- Optional detachable secondary temperature sensor
|
| | |
|
Data Logging Capabilities of the Model 8722 |
- Data logging ability allows user to log 14,000 samples with a time and date stamp
- Simultaneously records all parameters available
- Continuous data logging for cyclical monitoring and trend analysis
- Discrete data logging for taking spot measurements
- Data can be reviewed on-screen, printed or downloaded to a computer for easy report generation
- TSI LOGDAT™ downloading software permits easy transfer of data to a computer
- LOGDAT™ Companion Excel® Macro automatically graphs your data
- Statistics function displays average, maximum and minimum values, and the number of recorded samples
|
| |
|
Additional Information |
- Model 8720 includes: temperature, humidity, dew point, statistics, printer output and NIST Calibration Certificate
- Model 8722 includes: temperature, humidity, outside air, dew point, web bulb temperature, absolute humidity, data logging/downloading, statistics, review data, printer output and NIST Calibration Certificate
|
| | |
| |
Standard |
Advanced |
| Temperature |
• |
• |
| Humidity |
• |
• |
| % Outside Air |
|
• |
| Dewpoint |
• |
• |
| Web Bulb Temperature |
|
• |
| Absolute Humidity |
|
• |
| Data Logging/Downloading |
|
• |
| Statistics |
• |
• |
| Review Data |
|
• |
| Printer Output |
• |
• |
| NIST Calibration Certificate |
• |
• |
SPECIFICATIONS
|
Temperature (all models) |
| Sensor Type |
Thermistor |
| Temperature Range |
32-140°F (0 to 60°C) |
| Accuracy |
0.1°F (0.1°C) |
| Temperature (TS8722 only) |
| Sensor Type |
RTD |
| Range |
-40-392°F (-40 to 200°C) |
| Accuracy |
1.0°F (0.1°C) |
| Relative Humidity (all models): |
| Sensor Type |
Thin-film capacitive |
| RH Range |
5% to 95% RH |
| Accuracy |
2% RH |
| Absolute Humidity (TS8722 only): |
| Range |
1.51 E-05 to .00491 lbs moisture/ft3 |
| (0.24 to 79.0 g moisture/m3) |
| Wet Bulb Temperature (TS8722 only): |
| Range |
40 to 140°F (5 to 60°C) |
| Dewpoint Range |
5 to 120°F (-15 to 49°C) |
| Logging (TS8722 only): Up to 14,000 samples & 1,000 test id's |
| Intervals: 2 sec, 5 sec, 10 sec, 15 sec, 20 sec, 30 sec, 60 sec, 2 min, 5 min, 10 min, 15 min, 20 min, 30 min, 60 min |
| External Meter Dimensions (all models): 3.9 in. x 6.6 in. x 1.5 in |
| Probe Dimensions (all models): 5.81 in (14.5 cm), dia. 0.75 in (1.9 cm) |
| Power (all models): Four AA-size batteries (included) or ACadapter (optional) |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| TS8720 |
|
8720 |
|
TEMPERATURE, RH AND DEWPOINT METER WITH SOFT CASE |
|
Yes |
|
1,069,200
|
| TS8722 |
|
8722 |
|
TEMPERATURE, RHAND DEWPOINT METER WITH ADVANCED MEASUREMENTS, DATALOGGING AND SOFT CASE |
|
Yes |
|
1,933,200
| | |
|
|
 | |
 |
|
 |
|
