Features |
- Active Display — Oversized 4000 count LCD with display for test lead connection, blown fuse and power warnings
- PC Interface — Optional Windows® compatible software for storing and viewing data onto a computer
- Features Relative, Data Hold and Auto Power Off
- True RMS — Model EHMT330 with TRMS for accurate measurements in the presence of distortion or harmonics
- Advanced Functions — Models available with Capacitance, Frequency, Temperature and Duty Cycle
- Temperature — Wide °C/F temperature measurements (Models EHMT320 & EHMT330)
- Includes test leads with alligator clips, 9V battery, protective holster and temperature probe (Models EHMT320 & EHMT330)
|
|
Applications |
- Large display, multiple connection and voltage warnings, plus PC interface are ideal for training and technical schools
- Capacitance and diode functions useful for appliance installation and repair technicians
- DC functions, Duty Cycle and Capacitance for automotive & marine applications
|
|
| |
|
| SPECIFICATIONS
|
EHMT310 |
EHMT320 |
EHMT330 |
| Basic DC Volt Accuracy |
0.5% |
0.3% |
0.1% |
| AC Amp Range |
0.1μA to 20A |
0.1μA to 20A |
0.1μA to 20A (trms) |
| DC Amp Range |
0.1μA to 20A |
0.1μA to 20A |
0.1μA to 20A |
| AC Volt Range |
0.1mV to 700V |
0.1mV to 700V |
0.1mV to 700V (trms) |
| DC Volt Range |
0.1mV to 1000V |
0.1mV to 1000V |
0.1mV to 1000V |
| Ohms Range |
0.1Ω to 40MΩ |
0.1Ω to 40MΩ |
0.1Ω to 40MΩ |
| Capacitance Range |
0.01nF to 100μF |
0.01nF to 100μF |
0.01nF to 100μF |
| Frequency Range |
0.1mHz to 10MHz |
0.1mHz to 10MHz |
0.1mHz to 10MHz |
| Duty Cycle |
0.1% to 99.9% |
0.1% to 99.9% |
0.1% to 99.9% |
| Temperature Range (F/C) |
N/A |
0°F to 2000°F |
0°F to 2000°F |
| Continuity/Diode |
yes |
yes |
yes |
| RS 232 Interface |
yes |
yes |
yes |
| Software / Cable |
optional |
optional |
optional |
| Catalog No. |
Description |
Price |
| EHMT310 |
Digital MultiMeter |
163,404 |
| EHMT320 |
Digital MultiMeter with Temperature |
200,124 |
| EHMT330 |
True RMS MultiMeter with Temperature |
273,564 | | |
|
|
 | |
 |
|
 |
|
